Trapezoidal XL profile · 5.08 mm pitch
XL Series Standard Rubber Timing Belt
Classic XL-profile chloroprene rubber timing belt with fiberglass tensile cord. Suited for office machines, small drives, and instruments where quiet operation matters.
Features
- XL trapezoidal profile, 5.08 mm pitch
- Fiberglass tensile cord
- Operating temperature -30 °C to +80 °C
- Common widths: 0.37" / 0.50"
For inquiries about model 180XL037, please provide the existing belt markings, tooth profile, pitch, pitch length and width so the specification can be checked.
Follow the equipment manufacturer's installation and maintenance requirements. Confirm the specified belt tension and inspection procedure for the particular drive.
